Indexing and Searching Big Static Data

Static websites have kind of taken over in the last year or two. GitHub set the trend, with jekyll. I switched and so did MapBox and Development Seed, and a lot of their client sites - eliminating the ‘smart server’ of a website makes it much simpler to deploy and forget about.

tl;dr: I made a static open data portal with search & autocomplete by using an inverted index, trie, and sharding. You can try the code on other data, too.

Over the last year or two, the idea has been refined. I posted about fast hacky queries with UTFGrid, and a very-rethought version of that became the MapBox geocoder. The same basic rasterization-of-data-structures was expanded in Your Superfund, which used voronoi tesselations to do nearest-neighbor searches.

But there’s kind of a limit to what static sites can do. We assume that you can’t do things like search and advanced filtering with static data, especially with datasets that are too large to load in-browser.

Doing That Stuff Anyway

Set the scene. You’re working on your bike law project. You want to link to the laws that govern your life. You can’t because of evil companies you hate and bad government portals that crash.

So you scrape the data overnight. It’s 685MB of .doc files, 92MB when converted to text. Too big for browsers. Let’s do it anyway. First:

Enter the Inverted Index

Sidenote, read this about Google Code Search. It’s barely related but totally awesome.

An inverted index maps occurences of words to documents appeared in and, optionally, spots in that text. To crib an example from Russ Cox (read that article already):

(1) Google Code Search
(2) Google Code Project Hosting
-> Yields
Code: {1, 2}
Google: {1, 2}
Hosting: {2}
Project: {2}
Search: {1}

See? Inverted indexes are the basic building block of a search index. And they don’t require much power to use - you just need to load the index and do a bunch of AND clauses.

Let’s build an inverted index!

var w = _s.words(text), words = {};
w.forEach(function(word) {
    word = word.replace(/[^A-Za-z]/g, '').toLowerCase();
    if (word.length < 3) return;
    if (typeof words[word] !== 'object') words[word] = [];
    if (words[word].indexOf(id) === -1) words[word].push(id);
});

Bam, so easy. (okay, so that used underscore.string to get words and doesn’t have certain context) But building an inverted index of all of my text content makes an 8MB file, which is above my ‘browsers can do this’ threshold.

Here’s an example of an inverted index & a trie in action, using the code from this site, but applying it to Genesis.

So Then Comes Hashing & Sharding

Let’s split that up.

A hash function is like a one-way summary function. One hash function could be 'Hello'->4, 'Hi'->2, 'Goodbye'->7 - summarizing words by their number of letters. Another might be by adding all of the letters together,

Behold a shard function:

function shard(word) { return word[0]; }

Cool, right?

Okay, so combining the two means instead of having one 8MB inverted index, we have 26 shards of an inverted index, with the largest being around 800KB. Not too bad, and if this ended up being not enough, we could do something like

function shard(word) { return word.splice(0,2); }

And have smaller slices.

As far as how to actually use this index, it’s pretty easy. If you have a search term like bricked, you load the index b.json and it has a line like "bricked": [4861]. So, bricked appears in document 4861, so display that document in results and link to it. If you have multiple terms, load the indexes for each of them, and find the intersection of their results.

This is Trie

Cool! We now have an inverted index. So we can search for certain terms, and get a list of articles those terms appear within.

But it’s an exact search, and relatively blind. If you’re typing ‘bicycle’, you don’t get anything for ‘bicycles’, and you don’t get any results when you’ve just typed ‘bicy’.

This would be more useful with autocomplete. But how to do it?

There are multiple ways. One would be to just use the (sorted) list of entries and for-loop through it until you hit a word which is has your search term as a prefix. For n words, this would have approximately O(n) performance (look, I’m not a scientist, man). We can do better.

For this, I used a trie, aka a prefix tree. It’s a tree data structure in which each node has a letter of a word, and words that share prefixes share parts of the tree.

Play with it!

So, traversing the tree is pretty simple:

var pos = trie, prefix = '', strs = [];
for (var i = 0; i < last.length; i++) {
    if (pos[last[i]]) {
        prefix += last[i];
        pos = pos[last[i]];
    }
}
function traverse(pos, prefix) {
    if (strs.length > limit) return callback(strs);
    if (isEmpty(pos)) strs.push(prefix);
    for (var i in pos) traverse(pos[i], prefix + i);
}
traverse(pos, prefix);

And, as you can see, finding the right prefix subtree to traverse takes only as many steps as your prefix has letters, since each level of the tree is stored as an object.

Implementation

My implementation of these ideas is on GitHub, as well as an example data portal that displays the DC Municipal Regulations.

The regulations are available for download in full, and the implementations are stashed in generate_index of the GitHub repository.

There are plenty of things I didn’t do in this implementation that you would want to do. Most inverted indexes also store the point in the text where the word occurs. Or use a really compact datastructure. I did pull in a few of the normal tricks, not storing stop words to reduce noise in the index.
